11 KW Frequency Inverter, 3 Phase 220V, 400V, 460V
from
$634.44
Ex Tax: $634.44
- Stock: In Stock
- Model: GK3000-4T0110G
- Weight: 1.00
- SKU: GK3000-4T0110G
15 hp variable frequency drive inverter comes with a LCD screen, which can intuitively display parameter changes, and the multi-function keyboard can conveniently adjust the working status of the inverter.
Feature
- With RS485 communication, the frequency drive inverter's automatic voltage regulation (AVR) can keep a constant output voltage when the power source voltage varies.
- IP20 enclosure protection level of variable frequency drive inverter, strong impact resistance, and good safety performance.
- The 3 phase variable frequency inverter works at (–10℃, 40℃), and automatic current limiting can avoid frequent over-current which will cause a trip.
Details
Multiple Function Keyboard
The multiple-function keyboard of frequency inverters control the operation of the 3 phase variable frequency drive inverter, such as start, stop, and acceleration. The users can press the corresponding buttons to make the 11 kw three phase variable frequency drive work according to the set inverter parameters or control the inverter machine's operating speed.
Electronic Screen
The electronic screen of the frequency drive inverter is a key component in the control system, providing users with an intuitive and real-time information display. The electronic screen can monitor the operating status of the 11kw 3 phase variable frequency drive in real-time, including input and output voltage, and current waveform, which helps to detect abnormal conditions in time.
Rugged Casing
The 15hp variable frequency inverter's rugged casing plays multiple roles in its design. It is not only about protecting the circuits and internal components inside the device but also about the safety, stability, and reliability of the device. The 3 phase variable frequency drive not only protects the internal circuits and components but also provides safety protection.
Applications
Car Manufacturer
Ship Operation
Energy Generation
Building Construction
| Basics | Model | GK3000-4T0110G/ GK3000-2T0075G |
| Capacity | 11 kW (15 hp) | |
| Shipping weight | 11 kg | |
| Dimension | 339*231*214 mm | |
| I/O Feature | Rated current | 25A at 380V ~ 480V, 45A at 220V ~ 240V |
| Input voltage | 3 phase 230V /415V /480V AC ±15% (Optional) | |
| Input frequency | 50Hz/ 60Hz | |
| Output voltage | 3 phase AC 0~input voltage | |
| Output frequency | 0~1000Hz | |
| Over load capacity | 150% of rated current for 1 minute, 180% of rated current for 3 seconds | |
| Control Feature | Control mode | V/F control; Sensorless vector control; |
| Communication | RS485 | |
| Speed regulation | 1:100 | |
| Start torque | 150% of rating torque at 1 Hz | |
| Speed control accuracy | ≤±0.5% of rating synchronous speed | |
| Frequency precision | Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2% | |
| Frequency resolution | Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz | |
| Torque boost | Automatic torque boost, manual torque boost 0.1%~30.0% | |
| Interior PID controller | Be convenient to make closed-loop system | |
| Automatic energy save running | Optimize V/F curve automatically based on the load to realize power save running | |
| Automatic voltage regulation (AVR) | Can keep constant output voltage when power source voltage varies. | |
| Automatic current limiting | Limit running current automatically to avoid frequent over-current which will cause trip | |
| Environment | Enclosure rating | IP 20 |
| Temperature | –10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5% | |
| Humidity | 5%-95%, without condensation | |
| Altitude | ≤1000m; VFD will be derated if above 1000m | |
| Impingement and oscillation | Normal running:<5.9m 2="" (0.6g);=""><15m 2=""> | |
| Store environment | –20℃~ +60℃; no dust, no corrosive gas, no direct sunlight |
