1.5 KW Frequency Inverter, 3 Phase 230V, 400V, 480V
from
$218.41
Ex Tax: $218.41
- Stock: In Stock
- Model: GK3000-4T0015G
- Weight: 1.00
- SKU: GK3000-4T0015G
3 phase inverter with RS485 communication mode, work at (–10℃, 40℃), IP 20 enclosure rating. Frequency precision. Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2%. Usually applied for home electronics, motors, IT industry, and aviation/military units.
Feature
- The operation panel and control terminals of the frequency inverter can control the starting, speed regulation, stopping, braking, operating parameter settings, and peripheral equipment of the motor. It can be used in coffee machines, washing machines, juicers, microwave ovens, cassette players, refrigerators, vacuum cleaners, electric shavers, etc.
- The variable frequency drive inverter has V/F control and sensorless vector control.
- The vfd inverter 3 phase with RS485 communication and IP20 shell protection level has an LED display and a multi-function keyboard for easy operation.
- The 3 phase inverter has multiple functions such as automatic voltage stabilization, automatic current limiting, and automatic energy-saving operation.
Details
Multiple Function Keyboard
The keyboard of 3 phase inverter can control the operation of the frequency inverter, such as start and stop, acceleration, etc. The user can press the corresponding button to make the 1.5 kw inverter work according to the set inverter parameters or control the machine's operating speed by adjusting the output frequency to meet actual needs.
Electronic Screen
The screen of the frequency inverter is a key component in the control system, providing users with an intuitive information display. The electronic screen can monitor the operating status of the variable frequency inverter in real-time, including input and output voltage, and current waveform, which helps to detect abnormal conditions in time.
Rugged Casing
The 1.5 kw frequency inverter's rugged casing plays multiple roles in its design. It is not only about protecting the circuits and electronic components inside the device but also about the safety, stability, and reliability of the device. Frequency drive inverter not only protects the internal circuits and components but also provides safety protection.
Applications
Car Manufacturer
Ship Operation
Energy Generation
Building Construction
| Basics | Model | GK3000-4T0015G/GK3000-2T0015G |
| Capacity | 2 hp (1.5 kW) | |
| Shipping weight | 2 kg | |
| Dimension | 184*98*135 mm | |
| I/O Feature | Rated current | 3.8A at 380V ~ 480V, 5.1A at 220V ~ 240V |
| Input voltage | 3 phase 230V /400V /480V AC ±15% (Optional) | |
| Input frequency | 50Hz/ 60Hz | |
| Output voltage | 3 phase AC 0~input voltage | |
| Output frequency | 0~1000Hz | |
| Over load capacity | 150% of rated current for 1 minute, 180% of rated current for 3 seconds | |
| Control Feature | Control mode | V/F control; Sensorless vector control; |
| Communication | RS485 | |
| Speed regulation | 1:100 | |
| Start torque | 150% of rating torque at 1 Hz | |
| Speed control accuracy | ≤±0.5% of rating synchronous speed | |
| Frequency precision | Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2% | |
| Frequency resolution | Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz | |
| Torque boost | Automatic torque boost, manual torque boost 0.1%~30.0% | |
| Interior PID controller | Be convenient to make closed-loop system | |
| Automatic energy save running | Optimize V/F curve automatically based on the load to realize power save running | |
| Automatic voltage regulation (AVR) | Can keep constant output voltage when power source voltage varies. | |
| Automatic current limiting | Limit running current automatically to avoid frequent over-current which will cause trip | |
| Environment | Enclosure rating | IP 20 |
| Temperature | –10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5% | |
| Humidity | 5%-95%, without condensation | |
| Altitude | ≤1000m; VFD will be derated if above 1000m | |
| Impingement and oscillation | Normal running: 5.9m/s2 (0.6g); Transportation: 15m/s2 (1.5g) | |
| Store environment | –20℃~ +60℃; no dust, no corrosive gas, no direct sunlight |
