Solar Combiner Box, Photovoltaic System, 4/6/8/10 Array Input
from
$435.21
Ex Tax: $435.21
- Stock: In Stock
- Model: HZTOHZ-SCB-HT
- Weight: 1.00
- SKU: HZTOHZ-SCB-HT
Solar combiner boxes have a current-attack, over current protection, over-voltage protection and a series of perfect protection. Maximum open circuit voltage 1000V, with high voltage lightning protection device protection.
Features
- Single way photovoltaic array output, maximum open circuit voltage 1000V
- Multiway photovoltaic array input, single way input array maximum current of 10A
- Single way photovoltaic array to join the high-voltage fuse protection, counter-attack protection
- Photovoltaic special high voltage lightning protection device protection
- Photovoltaic special high voltage circuit breaker control output
- Meet outdoor installation requirements, protection class lp65
Detail
| Model | HZTOHZ-SCB | |||
| PV array input numbers | 4 | 6 | 8 | 10 |
| Max single PV array current | 16A | |||
| Single PV array fuse | 16A | |||
| Single PV array wire size | 4mm² | |||
| Number of output channel | 1 | 2 | ||
| Maximum output current | 40A | 60A in all (30A/output channel) | 80A in all (40A/output channel) | 100A in all (50A/output channel) |
| Wire number of each output channel | PG16, 8 mm2 for each output channel | PG16, 10 mm2 for each output channel | PG16, 10 mm2 for each output channel | PG16, 12 mm2 for each output channel |
| Maximum output voltage | 800VDC | |||
| DC output circuit breaker | Available | |||
| Protection | Ip65 | |||
| Temperature range | -30℃ ~ +60℃ | |||
| Reference weight(N.W/G.W.) | 7.6 Kg/13Kg | 12.2 Kg/18.8 Kg | ||
| Machine size (D X W X H) | 458*445*150mm | 458*445*150mm | ||
| Packaging size (D X W X H) | 510*500*252mm | 620*550*262mm | ||
| Cooling way | Natural cooling | |||
| SPD protection | 20KA-40KA | |||
| Ground wire size | ≥6mm² | |||
| Warranty | 1 year | |||
