5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V

5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V
5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V
5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V
5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V
5hp (3.7kW) VFD, 3 Phase 230V, 400V, 480V
0 reviews • Write a review
from Save -18%
$293.51
$359.80
Ex Tax: $293.51
  • Stock: In Stock
  • Model: HZTOHZ-G34
  • Weight: 1.00
  • SKU: HZTOHZ-G34

Available Options

Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
1 Hp (0.75 KW) Single Phase Output VFD
Quickview
1 Hp (0.75 KW) Single Phase Output VFD
$196.32 $220.00
Ex Tax:$196.32
Add to Cart Add to Wish List Compare this Product
1 Hp VFD, Single Phase To Three Phase VFD
Quickview
1 Hp VFD, Single Phase To Three Phase VFD
$159.32 $199.60
Ex Tax:$159.32
Add to Cart Add to Wish List Compare this Product
1/2 Hp VFD, Single Phase To Three Phase VFD
Quickview
1/2 Hp VFD, Single Phase To Three Phase VFD
$149.10 $197.00
Ex Tax:$149.10
Add to Cart Add to Wish List Compare this Product
10 Hp (7.5 KW) VFD, Three Phase 220V, 440V, 480V
Quickview
10 Hp (7.5 KW) VFD, Three Phase 220V, 440V, 480V
$463.25 $549.00
Ex Tax:$463.25
Add to Cart Add to Wish List Compare this Product
10 Hp VFD, Single Phase Input To Three Phase Converter
Quickview
10 Hp VFD, Single Phase Input To Three Phase Converter
$992.32 $1,109.98
Ex Tax:$992.32
Add to Cart Add to Wish List Compare this Product
100 Hp (75 KW) VFD, 3 Phase 230V, 400V, 460V
Quickview
100 Hp (75 KW) VFD, 3 Phase 230V, 400V, 460V
$3,197.41 $3,573.00
Ex Tax:$3,197.41
Add to Cart Add to Wish List Compare this Product

5 hp (4 kW) variable frequency drive, three phase 230V, 400V, 480V for selection.

Specification:

BasicsModelGK3000-4T0037G/ GK3000-2T0037G
Capacity5 hp (3.7 kW)
Shipping weight3 kg
Dimension230*118*153 mm
I/O FeatureRated current9A at 380V ~ 480V, 13A at 220V ~ 240V
Input voltage3 phase 230V /400V /480V AC ±15% (Optional)
Input frequency50Hz/ 60Hz
Output voltage3 phase AC 0~input voltage
Output frequency0.00~400.00Hz
Over load capacity150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control FeatureControl modeV/F control;
Sensorless vector control;
CommunicationRS485
Speed regulation1:100
Start torque150% of rating torque at 1 Hz
Speed control accuracy≤±0.5% of rating synchronous speed
Frequency precisionDigital setting: max frequency x± 0.01%;
Analog setting: max frequency x± 0.2%
Frequency resolutionAnalog setting: 0.1% of max frequency;
Digital setting: 0.01Hz
Torque boostAutomatic torque boost, manual torque boost 0.1%~30.0%
Interior PID controllerBe convenient to make closed-loop system
Automatic energy save runningOptimize V/F curve automatically based on the load to realize power save running
Automatic voltage regulation (AVR)Can keep constant output voltage when power source voltage varies.
Automatic current limitingLimit running current automatically to avoid frequent over-current which will cause trip
EnvironmentEnclosure ratingIP 20
Temperature–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
Humidity5%-95%, without condensation
Altitude≤1000m; VFD will be derated if above 1000m
Impingement and oscillationNormal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g)
Store environment–20℃~ +60℃; no dust, no corrosive gas, no direct sunlight



Tips: VFD vs Soft Starter in high starting torque application
Variable frequency drive (VFD) solution will solve in most cases the torque problem when using standard induction motor. Soft starter that reduce the toque might not deliver the required torque in effort to get to full speed. VFD with vector control is able produce higher torque in induction motor shaft than star delta or soft starter while also drawing less current from the power supply. This way you can have high torque during start, low current and after getting into full speed you bypass the VFD and save all the energy loses and noises that VFD caused.

If starting torque is not an issue in the installation, the start delta or soft starter are both OK. If you want to limit current rush in start or jam situation or you want to get higher starting torque then vector control VFD is a good selection and even better if closed loop with speed feedback from motor to VFD. Energy saving with VFD is achieved due to better control of magnetizing and rotor currents. It optimizes total current to motor thus reduces motor (and network) losses caused by excess current.
